Mastering ACM Panel Cutting with the Right Tools

Aluminum Composite Material (ACM) panels are a popular choice for signage, cladding, and architectural applications, but achieving clean, professional cuts requires the right router bit and technique. At Atlas Tools, we've developed specialized compression bits designed specifically for different ACM cutting scenarios.

Understanding ACM Cutting Challenges

ACM panels consist of two thin aluminum sheets bonded to a polyethylene core. This sandwich construction presents unique challenges:

  • Risk of delamination at cut edges
  • Potential for burrs on top and bottom surfaces
  • Chip evacuation issues in tight cuts
  • Surface finish quality on pre-finished panels

The Best Clean Path: ULTRACLEAN Compression Bit

For standard cutting operations where you need the cleanest possible edge finish, our Compression Spiral 1F - 3.175x12 (DLC Coating) ULTRACLEAN is the ideal choice.

Key Features:

  • Single flute design for optimal chip evacuation
  • DLC (Diamond-Like Carbon) coating for extended tool life and reduced friction
  • Compression geometry eliminates top and bottom surface burrs
  • 3.175mm diameter perfect for detailed work and standard cuts

Best Applications:

  • Long, straight cuts
  • Large panel trimming
  • Applications requiring maximum edge quality
  • Uncoated or factory-finished ACM panels

Recommended Settings:

  • RPM: 18,000-24,000
  • Feed rate: 5-7 m/min
  • Depth of cut: Full thickness in single pass

Small Shapes & Pre-Laid Vinyl: ULTRAPACK Compression Bit

When cutting intricate shapes, tight radii, or panels with pre-applied vinyl graphics, chip packing becomes a critical concern. Our Compression Spiral 1F - 3.175x12 (DLC Coating) ULTRAPACK is engineered specifically for these demanding applications.

Key Features:

  • Optimized flute geometry for superior chip packing in confined cuts
  • DLC coating prevents vinyl adhesive buildup
  • Compression design protects vinyl edges from lifting
  • Enhanced chip evacuation in tight corners and small radii

Best Applications:

  • Complex shapes with tight inside corners
  • Small lettering and detailed cutouts
  • Pre-laid vinyl or digitally printed panels
  • Nested parts with minimal spacing

Recommended Settings:

  • RPM: 18,000-22,000
  • Feed rate: 5-7 m/min (slower for vinyl protection)
  • Depth of cut: Full thickness in single pass
  • Consider climb cutting for vinyl edge protection

Pro Tips for ACM Routing Success

1. Secure Your Material Properly
Use vacuum hold-down or edge clamps to prevent panel movement and vibration during cutting.

2. Mind Your Speeds and Feeds
Too slow creates heat buildup and poor edge quality. Too fast can cause chipping and tool deflection.

3. Keep Tools Sharp
Dull bits cause delamination and poor surface finish. The DLC coating on our bits significantly extends tool life, but monitor for wear.

4. Use Proper Dust Extraction
Aluminum dust is conductive and can damage electronics. Always use adequate dust collection.

5. Test Your Settings
Run test cuts on scrap material, especially when working with pre-finished or vinyl-wrapped panels.

Choosing Between ULTRACLEAN and ULTRAPACK

Still not sure which bit to choose? Here's a quick decision guide:

Choose ULTRACLEAN when:

  • Cutting primarily straight lines or gentle curves
  • Maximum edge quality is the priority
  • Working with standard ACM panels
  • Chip evacuation space is adequate

Choose ULTRAPACK when:

  • Cutting complex shapes with tight radii
  • Working with pre-applied vinyl or graphics
  • Nesting multiple parts closely together
  • Chip packing is a concern

Get Professional Results Every Time

Both our ULTRACLEAN and ULTRAPACK compression bits feature premium construction, precision grinding, and advanced DLC coating technology. Whether you're running a high-volume sign shop or producing custom architectural panels, having both bits in your toolkit ensures you're prepared for any ACM cutting challenge.

Ready to upgrade your ACM cutting capabilities? Explore our full range of compression bits designed for composite materials and experience the Atlas Tools difference.
